Recurrent Symptoms After TAVR

81-year-old female status post previous Edwards Sapien transcatheter aortic valve replacement (TAVR), now presenting with recurrent symptoms of valvular aortic stenosis.

Figure 1.

A. Multiplanar reconstruction orthogonal to TAVR prosthesis, systolic phase (30% R-R interval). There is hypoattenuating leaflet thickening (HALT), most pronounced involving the right and non-coronary leaflets (arrowheads). The left leaflet (L) is less affected.

B. Blood pool inversion (BPI) volume rendering (VR) in same orientation as (A) shows restricted leaflet motion (RELM).

Patient demographics:
Height: 152 cm
Weight: 67 kg

CTA injection parameters:
Retrospective ECG synchronized CTA heart
Scan time: 6 sec (total)
Diagnostic (“trigger”) delay: 6 sec
Bolus tracing: Aortic root
Tube energy: 100 kVp

Contrast concentration: 370 mgI/mL
Contrast volume: 80 mL
Contrast flow rate: 4.0 mL/sec
Saline flush volume: 30 mL
Saline flow rate: 4.0 mL/sec

Video 1: BPI VR cine imaging shows HALT that results in RELM that is severe (>70% restriction) involving the right and noncoronary leaflets and mild (<50%) involving the left leaflet. Combination of HALT and RELM is considered hypoattenuation affecting motion (HAM).

All images, protocols, and outcomes are courtesy of Dr. Richard Hallett, Banner University Medical Center - Phoenix, Phoenix, AZ.
Individual results may vary.
